1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

Product Categories
Leyon steel Co., Ltd
Contact Now

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

Brand Name : leyon

Model Number : Hot Galvanized Malleable Fittings union

Certification : FM/UL

Place of Origin : China

MOQ : 500piece

Price : Negotiable

Payment Terms : Western Union, L/C, T/T, D/P, D/A, MoneyGram

Supply Ability : 10000piece/week

Delivery Time : 25-35days

Packaging Details : 200piece/carton

Specification : Elbow, socket, Tee, Union, Bushing, Plug

Item : 1/8 inch Hot Galvanized Malleable Fittings Tees

Application : Steam, air, gas and oil pipes

Technics : sophisticated metallurgical

technology : advanced metallurgical and processing

Treaded : ISO7/1, DIN2999,NPT

Size : 1/8 inch

Dimensions : 19 mm

Contact Now

Malleable Iron pipe fittings black plumbing fittings names and pictures male and female union

Details:

  • Female threaded straight union for 1-1/2" nominal pipe sizes
  • Black malleable iron construction for 150 lb. applications
  • Pressure tested at factory
  • UL and FM approved

Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements

Delivery details

 According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings

1/2" Malleable Iron Pipe Fittings ANAB Black Plumbing Fittings
